SDAT-17-1
程控衰减器 Programmable attenuator
工作频率 3-32GHz
Operating frequency: 3-32ghz
- 适用于通信系统场景模拟测量
Suitable for communication system scene simulation measurement - 宽带覆盖
Broadband coverage - 高速连续衰减调节
High speed continuous attenuation control - 支持LAN远程控制
Support LAN remote control
SDAT-17-1参数性能
| 参数 parameter | 典型值 Specification |
|---|---|
| 输入频率范围 Frequency Range (GHz) | 3～32 |
| 输入功率范围 Power Handing（dBm） | <35 |
| 信号输入带宽band width（MHz） | >112M |
| 插损 Insertion Loss (dB) | 5dB typ. |
| 驻波比VSWR | 1.5 |
| 可调衰减范围 Attenuation Range (dB) | 0～30 |
| 可调衰减步进 Attenuation Step（dB) | 0.1 |
| 可调衰减精度 Attenuation accuracy (dB) | ±0.1 |
| 衰减调节速率 Attenuation adjustment rate （dB/s） | 1～300① |
| 通道数量 number of channels | 1 |
① 衰减调节速率在可编程环境下可依定需求灵活设定,衰减量在调节过程中为线性变化
The above indicators are typical values, and some parameters of this series of products can be customized
① The attenuation adjustment rate can be set flexibly according to the fixed demand in programmable environment, and the attenuation is a linear change in the adjustment process
SDAT-17-1规格特征
| 规格Description | 特性Specification |
|---|---|
| 射频接口RF interface | 2*SMA-Female |
| 尺寸Physical Size | 180mm*100mm*50mm |
| 重量Weight | 1kg |
| 电源Power interface | 市电接口Mains plug |
| 功耗Power | 5W |
该产品为华为技术有限公司合作产品，详细细节请联系厂家
This product is a cooperative product of huawei technology co., LTD. Please contact the manufacturer for details
